A516 Hot Rolled Steel Plate
A516 hot rolled steel plate is a high-quality boiler and pressure vessel steel that is very suitable for low to medium temperature applications.
WhatsApp:+86 18906192815
Email:andrew@huiyingsteel.com
Contact Us
Products center

Product Description

A516 Hot Rolled Steel Plate Description

A516 plate can be divided into 4 grades according to its minimum tensile strength: grade 55, grade 60, grade 65 and grade 70. A516 steel plate not only has very high strength but also has very good toughness, wear resistance, fatigue resistance, impact resistance, easy welding processability and cold forming performance. It is often used in petrochemical container manufacturing industry such as pressure vessel manufacturing, reactors, heat-exchangers, petrochemical equipment, petroleum machinery, power station equipment, reactors, spherical tanks, nitrogen tanks, gas cylinders, liquefied gas tanks, etc..


Product Parameters

Product Name

A516 Hot Rolled Steel Plate

Production Process

Hot Rolling, Cold Rolling

Material Standards

AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.

Width

100mm-3000mm

Length

1m-12m, or Customized Size

Thickness

0.1mm-400mm

Delivery Conditions

Rolling, Annealing, Quenching, Tempered or Standard

Surface Process

Ordinary, Wire Drawing, Laminated Film



Chemical Composition

A516

C Thickness (mm)

Mn Thickness (mm)

Si

P

S

6-12.5 mm

12.5-25 mm

25-50 mm

> 50 mm

≤ 12.5 mm

> 12.5 mm

Level 55

0.18

0.20

0.22

0.25

0.55-0.98

0.60-1.30

0.13-0.45

0.035

0.035

Level 60

0.21

0.23

0.23

0.25

0.6-0.9

0.80-1.20

0.13-0.45

0.035

0.035

Level 65

0.24

0.26

0.26

0.28

0.85-1.20

0.85-1.20

0.13-0.45

0.035

0.035

Level 70

0.27

0.28

0.28

0.3

0.85-1.20

0.85-1.20

0.13-0.45

0.035

0.035



Mechanical Properties

ASTM A516



Tensile Strength

Yield

Lower limit of Elongation (%)

(MPa)

(MPa)

Gauge Length 50 mm

Gauge Length 200 mm

Level 55

380~515

205

27

23

Level 60

415~550

220

25

21

Level 65

450~585

240

23

19

Level 70

485~620

260

21

17



Physical Performance

Physical Performance

Metric

Imperial

Density

7.80 g/cc

0.282 lb/in³



Scope of Application

ASTM A516 boiler vessel plates are used in the manufacture of gas pressure vessels (liquefied petroleum gas, butane and propane tanks), steam boiler parts, compressors, etc.



Equivalent Material

American Standard

German Standard

European Standard

English Standard

ASTM

ASME

DIN 17155

EN 10028

Material No.

BS1501

Level 60

SA516 Gr.60

HII

P265GH

1.0425

161 430A

Level 65

SA516 Gr.65

17Mn4

P295GH

1.0481

-

Level 70

SA516 Gr.70

-

P355GH

-

224-490 A&B
